High Output Pvc Fascia Board Machine PVC Imitation Marble Slab Production Line
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Screw Design | Double-screw | Condition | New |
|---|---|---|---|
| Plastic Processed | PVC | Application | Plates |
| Weight | 7-10ton | Warranty | 1 Year |
| Key Selling Points | Best Services | Applicable Industries | Home Use, Construction Works , Advertising Company |
| Screw Diameter (mm) | 80 Mm | Voltage | 380V/3P/50HZ Or As Local Voltage |
| Dimension(L*W*H) | 25m*3m*1.5m | Power (kW) | 60 |
| After-sales Service Provided | Engineers Available To Service Machinery Overseas | Plastic Machine | Pvc Fascia Board Machine Manufacturer |
| Application Field | Construction Material | Screw Type | Conical Twin Screw |
| The Raw Material | Pvc Powder,CaCO3 And So On | Guarantee | 12 Months |
| Screw Material | 38CrMoAlA Nitriding | ||
| Highlight | Pvc Fascia Board Machine,PVC Imitation Marble Slab Production Extruder |
||
Product Description
High Output Pvc Fascia Board Machine Manufacturer With Discount Price/PVC Imitation Marble Slab Production Line
Machine Description of pvc fascia board machine manufacturer
The pvc fascia board machine manufacturer is specially designed for the extrusion of single layer or multi-layer PVC plate and sheet . It is also suitable for the sheet extrusion of PE , PP, PS, ABS and other materials.
PVC foam sheet/board is becoming the substitution of wood in many fields such as construction,advertisment and Decoration. It made through foaming and pressing into shape with additives. The main material is PVC. So it covers not only features of woodplast, but also very light and can be printed, engraved easily
| Introduction: | PVC Foam Board is the new man-made material, the main component is PVC, it has the fine chemical stability, anti-corrosive and high intensity, it can be the substitute of wood, it is widely used in the building, advertisement and decoration. |
| Features: | 1. Waterproofing. |
| 2. Fire retardant and self-extinguishing. | |
| 3. Heat preservation. | |
| 4. Sound-insulated. | |
| 5. Insulation. | |
| 6. Non-corrosion. | |
| 7. Non-toxic. | |
| 8. Tough, rigid with the high impact strength. | |
| 9. Stable color retention. | |
| Specifications: | Thickness (mm): 1 - 25 |
| Width (mm): 1220, 1560, 2050 (accept different widths) | |
| Length (mm): 2440, 3050, 6000 (accept different lengths) | |
| Color: white, black, red, blue, yellow, green, gray (customerized) |
Working Process of pvc fascia board machine manufacturer
Raw material → Autoloade for mixer → PVC mixer → Sping loader → Conical twin screw extruder → Board Mould
→ Die Lip temprature control sysem → Pvc board forming machine → Air cooling bracket
→ Board hauling off unit → Board Cutting unit → Dust vacuuming unit → Board stacker → Electri control box
Extruder: Appropriate Single-Screw Extruder (exhaust or not) or Conical Double Screw Extruder should be chosen on the basis of different materials. Specially designed screw and advanced temperature controlling system ensure the good plasticization, high output and stable extruding.
Screen changer and mould: The quick screen changer of hydraulic system ensures the short course of screen changing without material-leakage. Reasonable structure of mould should be chosen in terms of material, whereas moulds of clothes-rack mode are widely accepted to regulate flow-distribution and guarantee even thickness of plates (sheets).
vacuum sizing platform : It is consists of four groups(eight sets) calibrating bench,let the material become the foam board that want to get,through chaning it,we can change the thickness of the board.
Cooling bracket: Equipped with corresponding guide roller, the cooling effect is better. In addition, the edge-shearing device equipped can guarantee fixed width of plates (sheets) and quality of edge.
Hauling machine: It is consists of 2 groups rollers, let the board moving forward
Cutting machine: It is of length-fixed cutting with cutting precision less than 2mm and adopts alloy blade or rigid alloy saw bit to ensure the good cutting effect and constantly stable performance.
Machine lists of pvc fascia board machine manufacturer
| Item | Machine name | quantity |
| 1 | Extruder powder feeder | 1set |
| 2 | Double-screw extruder | 1set |
| 3 | mould &head(T-die) | 1set |
| 4 | Cooling Bracket | 1set |
| 5 | Calibration platform | 1set |
| 6 | Haul-off machine | 1set |
| 7 | Cutting machine | 1set |
| 8 | Stacker | 1set |
Final Production's features &application of pvc fascia board
Architecture: Such as building wall board, decoration board, housing, office, public building interlayer, commercial decoration shelf, non-dust room board, ceiling plate, etc.
Advertisement: Such as screen printing, computer lettering, ad board, etc.
Industry: cabinet board, chemical industry antisepticizing project, thermoforming for refrigerator, for temperature keeping for environment protection, etc.
Transportation: Such as steamship, aeroplane, carriage, train compartment, roof shed, case core layer, inner upholster, etc.
